Applications:
Petroleum Refining and Petrochemical Processing Equipment
Ore Processing
Sugar Processing
Chemical processing
Steam and gas turbines
Product material
Alloy 410 (UNS S41000) is a 12% chromium martensitic stainless steel that can be heat treated to obtain a wide range of mechanical properties. The alloy has good corrosion resistance along with high strength and hardness. In the annealed condition, 410 stainless steel is ductile and may be formed. It remains magnetic in both the annealed and heat treated conditions.
|
Standard |
Grade |
CHEMICAL COMPOSITION(%) |
Mechanical Properties |
||||||||
|
C (max) |
Mn (max) |
P (max) |
S (max) |
Si (max) |
Ni |
Cr |
TS,Min(Mpa) |
YS, Min(Mpa) |
Elongation in 2in. or 50mm, min% |
||
|
ASTM A268 |
TP410/S41000 |
0.15 |
1.00 |
0.04 |
0.03 |
1.00 |
- |
11.5-13.5 |
415 |
205 |
20 |
|
A268 martensitic stainless steel welded tube dimension range: |
||||||||||
|
O.D. |
Thickness inch(mm) |
|
|
|||||||
|
Inch |
mm |
0.028(0.71) |
0.035(0.89) |
0.049(1.24) |
0.065(1.65) |
0.083(2.11) |
0.095(2.41) |
0.109(2.77) |
0.12(3.05) |
0.128(3.25) |
|
1/8 |
3.18 |
X |
X |
|
|
|
|
|
|
|
|
1/4 |
6.35 |
X |
X |
X |
X |
|
|
|
|
|
|
3/16 |
4.76 |
|
X |
X |
|
|
|
|
|
|
|
5/16 |
7.94 |
|
X |
X |
X |
|
|
|
|
|
|
3/8 |
9.53 |
|
X |
X |
X |
|
|
|
|
|
|
1/2 |
12.7 |
|
X |
X |
X |
X |
|
|
|
|
|
5/8 |
15.88 |
|
|
X |
X |
X |
X |
|
|
|
|
3/4 |
19.05 |
|
X |
X |
X |
X |
X |
X |
X |
X |
|
1 |
25.4 |
|
X |
X |
X |
X |
X |
X |
X |
|
|
11/4 |
31.75 |
|
|
|
X |
X |
X |
X |
X |
|
|
11/2 |
38.1 |
|
|
|
X |
X |
X |
X |
X |
|
|
2 |
50.8 |
|
|
|
X |
X |
X |
X |
X |
|
|
ASTM A268 Dimension tolerance for martensitic stainless steel welded tube |
|||
|
O.D. mm |
O.D. tolerance(mm) |
Average Thickness Tolerance |
Permissible varaition in cut length |
|
＜1/2"(12.7),excl |
-0.13,+0.13 |
-15%,+15% |
-0/+3mm |
|
≥1/2" to 11/2" (12.7-38.1),excl |
-0.13,+0.13 |
-10%,+10% |
-0/+3mm |
|
≥11/2" to 31/2" (38.1-88.9),excl |
-0.25,+0.25 |
-10%,+10% |
-0/+5mm |
|
≥31/2" to 51/2"(88.9-139.7),excl |
-0.38,+0.38 |
-10%,+10% |
-0/+5mm |
|
≥51/2" to 8"(65-75), incl |
-0.76,+0.76 |
-10%,+10% |
-0/+5mm |
